224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯电站用启行为汽油经济发展性好: 优秀的汽油调控机设备，具有的STC、ESTC 分级a调控机设备，层次性结构设计的缸筒上方自燃室，高压电喷射式汽油，充足做雾化，自燃充足。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯电站用起心理瞬态特性优等: 美好的起心理整体上规划，听取康明斯现代感的EFC系統，调整高精准性高，积极响应准确时间快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯来发电用打火机升耗油率高: 总体制作紧凑型suv.外观设计布置设计有效率，启用平缓。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷外形 QSNT. QSK19. QSK38. QSK50符合要求我国的非市政道路最后阶段中及北美洲Tier2. Tier 3排放标准规范符合要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备品备件而犯性好， 起心理开机运行及维保清洁连锁便利店，价格低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

公率区间 Power Range   224-310KW结构类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观简约时尚图片尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净質量 Dry Weight   940kg

224-310KW康明斯发电机组用打着机的优点和缺点：占地小， 压缩的比低， 隔栅自然空气煮沸，适于再启动，活动车机供电的最佳的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打着机参数	适用耗油率(kW)Prime Power	预备公率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
